1.45 “ Small Size 60RGB×160 Dots TFT LCD Display Module Screen

General Description

Display Type	IPS-TFT-LCD
Brand name	WISEVISION
Size	1.45 inch
Pixels	60 x 160 Dots
View Direction	12：00
Active Area (A.A)	13.104 x 34.944 mm
Panel Size	15.4×39.69×2.1 mm
Color arrangement	RGB Vertical stripe
Color	65 K
Brightness	300 (Min)cd/m²
Interface	4 Line SPI
Pin Number	13
Driver IC	GC9107
Backlight Type	1 WHITE LED
Voltage	2.5~3.3 V
Weight	1.1g
Operational Temperature	-20 ~ +70 °C
Storage Temperature	-30 ~ +80°C

Product Information

N145-0616KTBIG41-H13 is a 1.45-inch IPS TFT-LCD with a resolution of 60*160 pixels. supports various interfaces such as SPI, providing flexibility for seamless integration into any project. The display's brightness of 300 cd/m² ensures clear, vivid visuals even in bright lighting conditions. The monitor uses the advanced GC9107 driver IC to ensure smooth and efficient performance. N145-0616KTBIG41-H13 adopts wide angle IPS (In plane Switching) technology. The viewing range is left: 50/right: 50/up: 50/down: 50degrees. a contrast ratio of 800:1, and an aspect ratio of 3:4 (typical value). The supply voltage for analog is from 2.5V to 3.3V (the typical value is 2.8V).The IPS panel has a wide range of viewing angles, bright colors, and high-quality images that are saturated and natural. This TFT-LCD module can work under temperatures from -20℃ to +70℃, and its storage temperatures range from -30℃ to +80℃.

Mechanical Drawing
